3 pole 1/4" cable jack, full metal, max. cable O.D. 6 mm
Presa jack 6,3 mm volante stereo interamente in metallo - Ø Esterno cavo: 6 mm
Product
- Connection Type Jack
- Gender female
Electrical
- Dielectric strength 0.5 kVDC
- Insulation resistance ≥ 1 Gohm
- Rated current depends on mated connector
- Contact resistance depends on mated connector
Mechanical
- Cable O.D. 6 mm
- Insertion force ≤ 20 N
- Withdrawal force ≥ 10 N
- Lifetime 1000 mating cycles
- Wiresize
Material
- Contact plating Nickel
- Contacts Brass (CuZn39Pb3)
- Shell Brass (CuZn39Pb3)
- Shell plating Nickel
- Strain relief SnCe plated, crimp type
- Insulation Thermoplastic
Environmental
- Solderability Complies with IEC 68-2-20
- Temperature range -25 °C to +70 °C
