KIT loop amplifier for desk
Kit amplificatore a loop magnetico per reception, banco, cassa e piccoli ambienti
Inputs
- Audio inputs: 2 (1 micro or line input and 1 line input)
- Type: 3.5 mm TRS-F mini-jack, Euroblock/Phoenix terminal block
- Phantom: 4.5V 1mA
Power supply
- Power supply: 12 VDC 1.5A
- Type: Separated power block
- MainsSystems: 230 V 50/60 Hz
- Power: 20 W max.
- Fuse: Thermal protection
Audio processor
- Compressor:Variable 1:1 to 20:1
- Etching: 10mS
- Descent: Automatic 500mS or 1500mS
- Noise reduction: Bandwith limits for 8 kHz total gain, 16 kHz to -6 dB
- Dynamic: > 60 dB
- THD: THD+N <0,5% at 1 kHz
Output
- Type: Current
- Loop resistance: 0,1 ohm to 1 ohm
- Peak current: 5A
- RMS Current: 3.5A at 1 kHz
- Protection: Thermal, short-circuit and start
Dimensions (mm) andWeight
- BM-KIT: 92 x 52 x 18 (L x H x P)
- Packaging: 190 x 190 x 50
- Weight: 0.350 kg
