Il Satura Profile™ è un profile dotato di una sorgente LED 440W High CRI >85 Cool White, che fornisce un totale di 20.000 lumen, un modulo framing shutter a 4 lame motorizzato all'avanguardia e uno zoom da 11° a 38°. È dotato di miscelazione del colore CMY più correzione lineare del colore CTO, 7 colori dicroici e bianco (aperto), 6 gobo in vetro e metallo rotanti e intercambiabili e 7 gobo statici in metallo stampati, prisma rotante a 3 facce, filtro wash frost, iride motorizzato, curve di dimmer variabili, DMX, RDM, supporto Art-NET, bloccaggio 3pin e 5pin DMX in/out, RJ45 Ethernet in/out e connessioni di alimentazione, funzionamento flicker free per TV e film e display reversibile a colori con 6 pulsanti di controllo. Ha un consumo massimo di 650W e un'alimentazione universale multitensione a commutazione automatica (120-240V).
FEATURES
440W Cool White 6,500K High CRI >85 LED Profile Luminaire
State-of-the-Art Motorized 4-Blade Framing Shutter Module
11° to 38° Motorized Zoom
Full CMY Color Mixing and Linear CTO Color Correction
3-Facet Rotating Prism
Low Heat, Quiet Operation, Hibernation Mode
Variable Dimming Curves
Flicker Free Operation for TV and film
Art-NET (DMX over Ethernet)
RDM – Remote Device Management
SOURCE
440W Cool White LED Engine
20,000 Lumen, 6,500K, High CRI >85
50,000 Hour Average LED Life*
PHOTOMETRIC DATA
11,200 LUX 1,040 FC @ 16.4’ (5m) (Min. Zoom)
5,854 LUX 544 FC @ 16.4’ (5m) (Max. Zoom)
EFFECTS
4-Blade Framing Shutter System
3-Facet Rotating Prism
Wash Frost Filter
Motorized Iris
Strobe: 1-18fps
Dimming: 0% - 100%
Variable Dimming Curves
COLOR
Full CMY Color Mixing and Linear CTO Color Correction
7 Dichroic Colors + White
GOBOS
6 Interchangeable / Rotating / Indexing Glass Gobos
Size Glass Gobos: OD 28.8mm / ID 24mm**
7 Interchangeable Static-Stamped Metal Gobos
Size Metal Gobos: OD 27mm / ID 22mm**
CONTROL / CONNECTIONS
(3) DMX Channel Modes (33 / 35 / 54)
RDM (Remote Device Management)
6 Button Touch Control Panel
Full Color 180° Reversible LCD Menu Display
Battery Powered Menu Display
8 / 16 Bit Resolution Adjustable Movement
3pin & 5pin DMX In/Out
RJ45 EtherCON In/Out (Art-NET)
powerCON Power In
SIZE / WEIGHT
Length: 17.7" (450mm)
Width: 20.7" (525mm)
Vertical Height: 29.3" (745mm)
Weight: 75.0 lbs. (34.0 kg)
ELECTRICAL / THERMAL
AC 100-240V - 50/60Hz
650W Max Power Consumption
14°F to 113°F (-10°C to 45°C)
OPTIONAL ACCESSORIES
1227000013 WP-02 Outdoor Dome
1227000018 WP-06 Outdoor Dome
1322000054 E Loader III
1521000240 Touring Case 2x Satura Profile
1521000241 PRO Case 2x Satura Profile
*LED Life may vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.
**OD = Outside Diameter | ID = Image Diameter Due to varying manufacturing processes, it is highly recommended to provide a gobo and holder sample from the fixture to 3rd party custom gobo vendors for accurate sizing.
