Il sagomatore IP65 WW Profile HP IP™ è dotato di un LED Warm White 3.000K ad alta potenza da 130W con CRI maggiore di 91, che produce 11.000+ lumen totali. Può montare ottiche intercambiabili da 19°, 26°, 36° e 50° (vendute separatamente), ha un sistema di framing manuale a quattro lame in un corpo ruotabile, messa a fuoco manuale, strobo elettronico, modalità di curva dimmer variabile, frequenza di aggiornamento regolabile e luminosità gamma per il funzionamento senza sfarfallio per TV e film, DMX, RDM, connettori DMX da 3/5pin e connessioni powerCON TRUE1 in/out, pannello di controllo LCD con 4 pulsanti, un supporto di rigging integrato e raffreddamento a ventola silenzioso. Supporta gobo in metallo di taglia B o trasparenti HT, iride regolabile e un ruota gobo opzionale. Ha un consumo massimo di 160W e un alimentatore universale multitensione a commutazione automatica (100-240v).
FEATURES
IP65 Rated Dust and Water Protection
Very Efficient Single-Color LED Profile
High CRI >91, 10,000 Lumen
77 Lumen per Watt
4-Blade Manual Framing Module in Rotatable Barrel
Interchangeable Lens Options (19°, 26°, 36°, 50°)**
Supports B Size Metal or HT Transparency Gobos
Supports Adjustable Iris
Supports IP Gobo Rotator**
Quiet Fan Cooling
Adjustable Refresh Frequency and Gamma Brightness
Variable Dimming Curves
Flicker Free Operation for TV and film
RDM – Remote Device Management
SOURCE
130W Warm White LED Engine
10,000 Lumen, >91CRI, 3,000K
50,000 Hour Average LED Life***
PHOTOMETRIC DATA
13,018 LUX 1,209 FC @ 9.8’ (3m)*
EFFECTS
Supports Adjustable Iris
Strobe: 1-18fps
Dimming: 0% - 100%
Variable Dimming Curves
GOBOS
Supports IP Gobo Rotator**
Supports B Size Metal or HT Transparency Gobos
Gobo Size: OD 86mm / ID 64mm / Thickness 0.15mm
CONTROL / CONNECTIONS
(2) DMX Channel Modes (3 / 6 / 8)
RDM (Remote Device Management)
Adjustable Refresh Frequency (900 – 25,000Hz)
Adjustable Gamma Brightness (2.0, 2.2, 2.4, 2.8)
4 Button Control Panel
LCD Menu Display
3pin & 5pin DMX In/Out
powerCON TRUE1 Power In/Out
SIZE / WEIGHT
Length: 24.3" (618mm)
Width: 12.2" (310mm)
Vertical Height: 15.7" (398mm)
Weight: 21.0 lbs. (9.5 kg)
ELECTRICAL / THERMAL
AC 100-240V - 50/60Hz
160W Max Power Consumption
14°F to 113°F (-10°C to 45°C)
OPTIONAL ACCESSORIES
1322000054 E Loader III
1236100117 PHDL19 Lens for LED Profile
1236100118 PHDL26 Lens for LED Profile
1236100119 PHDL36 Lens for LED Profile
1236100120 PHDL50 Lens for LED Profile
1236100128 Goboholder for LED Profile
1236100164 IP Gobo Rotator
*with 26° lens
**sold separately
***LED Life may vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.
