L'EWDMX IP™ è un transceiver DMX wireless, classificato IP65, da un singolo universo DMX-512 con un'antenna esterna da 2dbi. È dotato di una portata DMX wireless fino a 500m (1.640 piedi), FHSS (Frequency Hoping Spread Spectrum) di 1.800 tps, tecnologia data safe che fornisce fedeltà wireless e correzione degli errori, tecnologia ad alta fedeltà invisi-wire che fornisce un ingresso corrispondente all'uscita, facile da usare tramite il controllo della funzione/modalità con un solo pulsante, supporto RDM, TDMA (Time Division Multiple Access), supporto del protocollo W-DMX G4, una robusta custodia in plastica rigida e un alimentatore universale a commutazione automatica multitensione (100-240v).
FEATURES
IP65 Wireless DMX Transceiver with 2dbi Outdoor Antenna
Up To 1,640 ft. (500m) Wireless DMX Range*
FHSS (Frequency Hoping Spread Spectrum) 1,800 tps
Datasafe Tech - Wireless Fidelity and Error Correction
Invisi-Wire High-Fidelity Tech - Output Matches Input
Easy-To-Use Single Push Button Function Control
RDM (Remote Device Management) Support
2.4GHz Radio – License Free Worldwide
TDMA (Time Division Multiple Access)
W-DMX G4 Protocol Support
Rugged Hard Plastic Case
Single DMX-512 Universe
CONTROL / CONNECTIONS
Multi-Function Single Push Button
Antenna Port
IP 3pin Male + Female Attached DMX In/Out Cables
IP 3pin Attached Power in Cable
WIRELESS RANGE
Up To 1,640 ft (500m)*
*Based on general testing of the EWDMX IP™ in an outdoor urban area with normal interference, instalLED in a location 9.8 ft. (3m) ABOVE AUDIENCES and/or GROUND LEVEL, with a DIRECT LINE OF SIGHT (Tx Antenna to Rx Antenna), and with 80% or greater signal strength.
SIZE / WEIGHT
Length: 9.4" (240mm)
Width: 6.7" (170mm)
Vertical Height: 2.2" (56.5mm)
Weight: 4.6 lbs. (2.1kg)
ELECTRICAL / THERMAL
AC 100-240V - 50/60Hz
3W Max Power Consumption
14°F to 113°F (-10°C to 45°C)
INCLUDED ITEMS
(1) IP Rated Power Cable
(1) IP Rated 3pin Male DMX Input Cable
(1) Clamp Mounting Bracket & (2) Screws
(1) Safety Cable
