| IC | ICN2153 |
| Dimension | 960 x 960 mm |
| Pixel pitch | 8 mm |
| LED Configuration |
1R1G1B |
| LED type | SMD2727 |
| Cabinet resolution | 128 x 128 pixel |
| Physical density | 15,625 pixel/m2 |
| Brightness | ≥ 6000 cd/m2 |
| Contrast | ≥ 2000:1 |
| Scan method | 1/4 |
| Max. power consumption | 800 W/m2 |
| Avg. power consumption |
280 W/m2 |
| Cabinet weight | 35 kg/pc |
| Refresh rate | ≤ 3840 Hz |
| IP rating | IP65/IP54, outdoor |
| Control mode | synchronous display with control PC by DVI |
