| IC | ICN2046 |
| Dimension | 800 x 900 mm |
| Pixel pitch | 8.33 mm |
| LED type | SMD2727 |
| Panel resolution | 96 x 108 pixel |
| Physical density | 14,400 pixel/m2 |
| Brightness | ≥ 6500 cd/m2 |
| Scan method | 1/3 scan |
| Max. power consumption | 600-800 W/m2 |
| Ave. power consumption | 320 W/m2 |
| Weight | 22.5 kg/panel |
| Refresh rate | ≤ 1920 Hz |
| Control mode | synchronous display with control PC by DVI |
| Protection level | IP65, outdoor |
