Registra tutti i formati fino a 2160p30 sul tuo computer con il DeckLink Mini Recorder 4K. Questa scheda di acquisizione PCI Express a basso profilo dispone di 6G-SDI e delle ultime connessioni HDMI 2.0a. Gli ingressi SDI e HDMI rilevano e passano automaticamente tra tutti i formati video. La scheda permette la registrazione ad alta gamma dinamica e i metadati su HDMI. Con Blackmagic Desktop Video SDK per Mac OS, Windows e Linux puoi anche sviluppare le tue soluzioni di acquisizione personalizzate. Sono inclusi due piastre PCI Express sia per gli slot ad altezza intera che per quelli a basso profilo.
Connections
SDI Video Inputs 1 x 10-bit SD/HD/Ultra HD switchable.
SDI Audio Inputs 16 channels embedded in SD, HD, Ultra HD.
HDMI Video Inputs 1 x HDMI 2.0a connector.
HDMI Audio Inputs 8 Channels embedded in SD, HD, Ultra HD.
Computer Interface PCI Express 4 lane generation 2, compatible with 4, 8 and 16 lane PCI Express slots.
Supported Codecs
AVC-Intra, AVCHD, Canon XF MPEG2, Digital SLR, DV-NTSC, DV-PAL, DVCPRO50, DVCPROHD, DPX, HDV, XDCAM EX, XDCAM HD, XDCAM HD422, DNxHR & DNxHD, Apple ProRes 4444, Apple ProRes 422 HQ, Apple ProRes 422, Apple ProRes LT, Apple ProRes 422 Proxy, Uncompressed 8-bit 4:2:2, Uncompressed 10-bit 4:2:2.
Software
Software Included Media Express, Disk Speed Test, LiveKey, Blackmagic Desktop Video Utility and Blackmagic driver on Mac OS and Windows. Media Express, Blackmagic Desktop Video Utility and Blackmagic driver on Linux.
Internal Software Upgrade Firmware built into software driver. Loaded at system start or via updater software.
Physical Installation PCI Express 4 lane generation 2, compatible with 4, 8 and 16 lane PCI Express slots on Mac OS, Windows and Linux. Mac OS systems require a Mac Pro computer with PCI Express slots. Please check the Support pages to see the full system requirements.
Video Standards
SD Video Standards 525i59.94 NTSC, 625i50 PAL
HD Video Standards 720p50, 720p59.94, 720p60 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60; 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30 1080i50, 1080i59.94, 1080i60
2K Video Standards (SDI ONLY) 2K DCI 23.98p, 2K DCI 24p, 2K DCI 25p; 2K DCI 23.98PsF, 2K DCI 24PsF, 2K DCI F25PsF
Ultra HD Video Standards 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30
4K DCI Video Standards 4K DCI 23.98p, 4K DCI 24p, 4K DCI 25p*. *SDI only.
SDI Compliance SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 425M, SMPTE 2081, ITU-R BT.656 and ITU-R BT.601.
SDI Metadata Support RP 188/SMPTE 12M-2 and closed captioning.
Audio Sampling Television standard sample rate of 48 kHz and 24 bit.
SDI Video Sampling 4:4:4 & 4:2:2
SDI Color Precision 8, 10, 12-bit RGB 4:4:4 in all modes up to 1080p60, and 8, 10-bit YUV 4:2:2 in all modes.
Color Space REC 601, REC 709
HDMI Video Sampling 4:4:4, 4:2:2 & 4:2:0
HDMI Con guration HDMI 2.0a supports Deep Color and HDR.
HDMI Color Precision Up to 12-bit (Deep Color)
Multiple Rate Support HDMI and SDI video connections are switchable between SD/HD/2K and 4K.
Copy Protection HDMI input is unable to capture from copy protected HDMI sources. Always con rm copyright ownership before capture or distribution of content.
