UltraStudio HD Mini - All-in-one capture and playback SDI and HDMI card up to 1080p60

All-in-one capture and playback SDI and HDMI card up to 1080p60

Ottieni connessioni professionali di qualità broadcast con l'UltraStudio HD Mini. Sono inclusi ingressi video 3G-SDI, YUV analogico e composito NTSC/PAL, insieme a un ingresso di riferimento. L'UltraStudio HD Mini dispone anche di due connessioni audio da ¼" per l'ingresso audio analogico che funzionano con sorgenti bilanciate e HiFi. La connessione RS-422 incorporata permette di controllare a distanza i deck professionali di broadcasting. L'uscita è dotata di dual link 3G-SDI con fill e key, e di una connessione HDMI, in modo da poter monitorare il video con uno schermo di grandi dimensioni.

• Soluzione portatile Thunderbolt 3 di acquisizione e riproduzione.
• Formati di qualità broadcast a 10 bit fino al 1080p60 e 2K DCI.
• Ideale per acquisire e riprodurre video ad alta definizione.
• 40 Gb/s per riprodurre formati 4:4:4:4 con riempimento e chiave.
• Ingressi YUV analogici e NTSC/PAL per acquisire materiale d’archivio.

Connections

SDI Video Inputs 1 x 3Gb/s SD/HD switchable.

SDI Video Outputs 2 x 3Gb/s SD/HD switchable, supports ll and key.

SDI Rates 270Mb, 1.5G, 3G

Optical SDI None

HDMI Video Inputs None

HDMI Video Outputs 1 x HDMI 1.4b type A connector.

Analog Video Inputs Y, B-Y, R-Y/NTSC/PAL.

Analog Video Outputs None

Analog Audio Inputs 2 x 1/4 inch jack connectors for balanced and unbalanced analog audio.

Analog Audio Outputs None, embedded audio only.

SDI Audio Inputs 16 Channels embedded in SD and HD.

SDI Audio Outputs 16 Channels embedded in SD and HD.

HDMI Audio Outputs 2 Channels embedded in SD and HD.

Time Code Connection None. RP-188 only.

Reference Input Tri-Sync or Black Burst.

Supported Codecs

AVC-Intra, AVCHD, Canon XF MPEG2, Digital SLR, DV-NTSC, DV-PAL, DVCPRO50, DVCPROHD, DPX, HDV, XDCAM EX, XDCAM HD, XDCAM HD422, DNxHD, DNxHR, Apple ProRes 4444, Apple ProRes 422 HQ, Apple ProRes 422, Apple ProRes LT, Apple ProRes 422 Proxy, Uncompressed 8-bit 4:2:2, Uncompressed 10?bit 4:2:2.

Software

Software Included Media Express, Disk Speed Test, LiveKey, Blackmagic Desktop Video Utility and Blackmagic driver on Mac OS X and Windows. Media Express, Blackmagic Desktop Video Utility and Blackmagic driver on Linux.

Internal Software Upgrade Firmware built into software driver. Software driver loads upgrades at system start or via updater software.

Video Standards

SD Video Standards 525i59.94 NTSC, 625i50 PAL

HD Video Standards 720p50, 720p59.94, 720p60 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60; 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30 1080i50, 1080i59.94, 1080i60

2K Video Standards 2K DCI 23.98p, 2K DCI 24p, 2K DCI 25p, 2K DCI 23.98PsF, 2K DCI 24PsF, 2K DCI 25PsF

Ultra HD Video Standards None

4K Video Standards None

SDI Compliance SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M and SMPTE 425M A/B.

SDI Metadata Support RP 188/SMPTE 12M-2 and closed captioning.

Audio Sampling Television rate of 48 kHz and 24 bit.

SDI Video Sampling 4:2:2/4:4:4

Color Space REC 601, REC 709.

HDMI Resolution Pixel for pixel HD resolution input from connected device.

Multiple Rate support SDI and HDMI video connections are switchable between standard de nition and high de nition. SDI switches between 270 Mb/s, 1.5 Gb/s and 3 Gb/s.
