L'ATEM 1 M/E Production Studio 4K di Blackmagic Design è un modello avanzato che permette di switchare tra gli standard video SD, HD o Ultra HD, per collegare una vasta gamma di fonti video come telecamere, registratori a disco e computer. Include 10 ingressi, chroma keys, transizioni, media pool, 4 upstream keyers, downstream keyers, mixer audio, multi view, full motion DVE, transizioni stinger, ampio media pool con clip full motion e anche 3 uscite ausiliarie.
Total Video Inputs 11 with 10 active.
Total Video Outputs 10
Total Aux Outputs 3
SDI Rates 270Mb, 1.5G, 3G, 6G
Total Audio Inputs 2 x XLR. 2 x RCA.
Total Audio Outputs 2 x XLR Program.
Time Code Connections None
Reference Input Tri-Sync or Black Burst.
Video Input Re-Sync On all 10 inputs.
SDI Video Inputs 10 x 10-bit SD/HD/Ultra HD 4K switchable. 2 channel embedded audio.
HDMI Video Input 1 x HDMI type A. 10-bit SD/HD/Ultra HD 4K switchable. 2 channel embedded audio.
Analog Audio Outputs 2 x XLR.
SDI Audio Outputs 2 Ch embedded into SDI output on all outputs.
SDI Program Outputs 2 x 10-bit SD/HD/Ultra HD 4K switchable.
HDMI Program Outputs 1 x HDMI type A, 10-bit SD/HD/Ultra HD 4K switchable.
Down Converted SDI Program Output 1 x 10-bit (Ultra HD 4K to HD)
SDI Preview Output 1 x 10-bit SD/HD/Ultra HD 4K switchable.
Control Panel Connection Ethernet supports 10/100/1000 BaseT. Allows direct connection between panel and chassis, or via network.
Tally Output Added via ethernet connection to Blackmagic Design GPI and Tally Interface product. (Not included.)
Computer Interface 1 x USB 2.0 port.
