Blackmagic Studio Camera 4K Pro G2 - Compact professional broadcast camera designed for studio production, cinematic image quality, Super 35 sensor, advanced controls, Blackmagic RAW recording via USB-C, professional 12G-SDI and 10G Ethernet connections

Compact professional broadcast camera designed for studio production, cinematic image quality, Super 35 sensor, advanced controls, Blackmagic RAW recording via USB-C, professional 12G-SDI and 10G Ethernet connections

Blackmagic Studio Camera 4K Pro G2 vanta le stesse funzioni delle grandi telecamere da studio, ridotte però in un formato compatto e portatile. Rispetto alla Studio Camera 4K Plus G2, vanta un sensore Super 35 e baionetta per il montaggio di obiettivi Canon EF, più altre funzionalità aggiuntive.

Questo modello, con connettività professionale 12G-SDI e 10G Ethernet, è progettato per le configurazioni in cui la camera e i potenti switcher SDI sono molto distanti tra loro. Include un’uscita 12G-SDI e un ingresso 12G-SDI - per il ritorno di programma completo di controllo camera, talkback e Tally - e un’efficiente uscita HDMI con funzioni di controllo.

La connessione 10G Ethernet convoglia tutti i segnali in un solo cavo, per workflow in stile SMPTE nettamente più economico.

Technical characteristics

Camera features

• Effective sensor size: 23.10 x 12.99 mm (Super 35)
• Lens mount: active EF mount
• Lens control: iris, focus, zoom on supported lenses
• Dynamic range: 13 stops
• Dual native ISO: 0 dB and 18 dB gain
• Sensitivity at 0 dB gain: f11 with 2160p59.94, f12 with 2160p50 at 2000 lux with 89.9% reflectance
• Signal to noise ratio: 64.62 dB for 2160p
• Recording resolutions:  6144 x 3456 (6K) up to 50 fps 6144 x 2560 (6K 2.4:1) up to 60 fps 5376 x 3024 (5.3K 16:9) up to 60 fps 3840 x 2160 (Ultra HD) up to 60 fps
• Frame rates: 23.98, 24, 25, 29.97, 30, 50, 59.94 and 60 frames per second. Off-speed frame rates 5 ‑ 50 fps in 6K, and 5 ‑ 60 fps for all other recording resolutions
• Built in ND filters: four position ND filter with clear, 2‑stop, 4‑stop and 6‑stop IR ND filters
• Focus: auto focus available using compatible lenses
• Screen dimensions: 1920 x 1200 (7 inch)
• Screen type: LCD capacitive touchscreen
• Screen brightness: 2000 nits
• Controls: touchscreen camera settings and menus with rotary settings dial, program button, F1, F2 and F3 assignable function buttons, brightness contrast and peaking dials
• Mounting options: 2 x 1/4 inch tripod mount, 1 x 3/8 inch tripod mount

Connections

• SDI video inputs: 1
• SDI video outputs: 1
• SDI rates: 1.5G, 3G, 6G, 12G
• HDMI 2.0 video outputs: 1
• Analog audio input: 2 x XLR analog switchable between mic and line levels with phantom power support, 1 x 3.5 mm stereo input (can also be used for timecode input)
• Analog audio output: 1 x 5-pin XLR for talkback headset, 1 x 3.5 mm TRRS mini jack for headphones with mic
• Reference inputs: Tri-sync or Black Burst when used with optional Blackmagic Studio Converter
• Program input: SDI input on camera or on Blackmagic Studio Converter
• SDI audio output: 2 channels of program audio embedded in 1.5G/3G/6G/12G-SDI, 2 talkback channels on 15 and 16
• Remote control: remote camera control over SDI, HDMI or Ethernet
• Ethernet: 10 Gb/s
• Computer interface: 2 x USB Type-C 3.1 Gen 1 (up to 5 Gb/s) expansion ports for external recording and focus/zoom demand connection, software updates using USB-C Port A

Audio

• Microphone: integrated stereo microphone
• Built in speaker: 1 x mono speaker

Streaming

• Direct streaming: Blackmagic Studio Camera 6K Pro supports direct live streaming using Real Time Messaging Protocol (RTMP) over ethernet or a shared mobile internet connection over USB‑C
• Streaming platforms: ATEM Television Studio HD8 ISO, ATEM Streaming Bridge, Facebook, Twitch, YouTube, Twitter, Restream.IO, Vimeo, BoxCast, Castr, Afreeca TV, Bilibili, DouYu, Weibo

Standards

• SD video standards: none
• HD video standards: 1080i50, 1080i59.94, 1080i60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
• Ultra HD video standards: 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60
• SDI compliance: SMPTE 292M, SMPTE 424M, SMPTE 425M level A and B, SMPTE 2081-1, SMPTE 2081-10, SMPTE 2082-1, SMPTE 2082-10
• SDI audio sampling: television standard sample rate of 48 kHz and 24 bit
• HDMI audio sampling: television standard sample rate of 48 kHz and 24 bit

Media

• Media: 2 x USB-C 3.1 Gen 1 expansion ports for external media for recording Blackmagic RAW
• Media format: can format media to ExFAT (Windows/Mac) or HFS+ (Mac) file systems

Supported codecs

• Blackmagic RAW Constant Bitrate 3:1, Blackmagic RAW Constant Bitrate 5:1, Blackmagic RAW Constant Bitrate 8:1, Blackmagic RAW Constant Bitrate 12:1, Blackmagic RAW Constant Quality Q0, Blackmagic RAW Constant Quality Q1, Blackmagic RAW Constant Quality Q3, Blackmagic RAW Constant Quality Q5

Storage features

• Storage type: 2 x USB-C 3.1 Gen 1 expansion ports for external media
• Recording formats: Blackmagic RAW 3:1, 5:1, 8:1, 12:1, Q0, Q1, Q3 and Q5 in 6K (6144 x 3456), 6K 2.4:1 (6144 x 2560), 5.3K 16:9 (5376 x 3024), Ultra HD (3840 x 2160) at the selected frame rate
• Storage rates: please see the user manual

Control

• External control: Blackmagic Zoom Demand and Blackmagic Focus Demand for controlling your camera and lens from tripod handles. Blackmagic Control Protocol over SDI, RTMP and HDMI for external control when used with a compatible ATEM switcher with ATEM Software Control or ATEM Camera Control Panel. Includes control of some camera settings, focus, iris and zoom with compatible lenses, color corrector, tally and record start and stop to external media via USB expansion port. Camera Control REST API over Ethernet or USB Ethernet for external control via HTTP when used with REST client applications such as Postman

Network management

• NTP: Network Time Protocol support allows you to sync the time on your camera whenever connected to a network with any NTP server of your choice
• Web media manager: using a browser connected over Ethernet, web media manager allows you to access, browse, download and delete files from any drive connected to the camera
• FTP: download files from any drive attached to your camera using FTP
• SMB: file sharing using SMB

Color corrector

• Color corrector: DaVinci YRGB

Talkback and Tally

• Live tally indicator: 1 x front facing for talent, 1 x rear facing for operator
• Talkback: SDI channels 15 and 16

Software

• Software included: Blackmagic Camera Setup for Mac and Windows

Operating systems

• Mac: macOS 13.0 Ventura, macOS 14.0 Sonoma or later
• Windows: Windows 10 and 11

Power requirements

• Power supply: 1 x external 12 V_DC 60W power supply
• Power inputs: 1 x 12 V_DC locking 5.5 mm barrel connector, 1 x 12 V_DC 4 pin XLR input for external power supply or battery use, 1 x RJ45 Ethernet connector for power from Type 4 PoE power supplies
• Power usage: 26 ‑ 40 W using DC input, 30 ‑ 46 W using PoE input

Optional accessories

• Blackmagic Focus Demand
• Blackmagic Zoom Demand
• Blackmagic Studio Converter
• ATEM Mini switchers
• ATEM SDI switchers
• ATEM Constellation switchers
• ATEM Television Studio switchers
• ATEM Streaming Bridge
• Blackmagic MultiDock 10G
• HyperDeck Studio HD Plus
• HyperDeck Studio 4K Pro
• W-HDL-09
• Blackmagic Cloud Pod
• Blackmagic Cloud Store
• Blackmagic Cloud Store Mini 8TB
• Ultimatte 12 HD Mini
• Ultimatte 12 HD
• Ultimatte 12 4K
• Blackmagic 3G SDI Shield for Arduino

Environmental specifications

• Operating temperature: 0 to 40 °C
• Storage temperature: –20 to 45 °C
• Relative humidity: 0 to 90% non-condensing

Physical specifications

• Dimensions: 27.36 x 16.73 x 16.97 cm
• Weight: 1.68 kg

What's included

• Blackmagic Studio Camera 6K Pro
• Blackmagic Studio Camera Sun Shade
• Tripod Mount compatible with 15mm lightweight rails
• Tripod Mount Plate
• Turret Dust Cap
• External 12V DC power supply with locking connector and international sockets adapters for most countries.
• Welcome wallet with QR code for software download
• DaVinci Resolve download card
• Blackmagic Design sticker
