Ultra-compact 4K studio camera with 12G-SDI, HDMI, and Genlock, featuring a 4/3 HDR sensor, MFT lens mount and remote control via ATEM switchers
Blackmagic Micro Studio Camera 4K G2 è una straordinaria camera per la produzione dal vivo di qualità broadcast racchiusa in un corpo di piccole dimensioni.
Il sensore Micro 4/3 offre 13 stop di gamma dinamica e prestazioni eccezionali in condizioni di scarsa luce, generando immagini Ultra HD meravigliose. I connettori micro BNC 12G-SDI accettano video non compresso a 10 bit fino al 2160p 60 e audio a due canali in uscita. L’ingresso supporta i segnali di controllo Tally, camera, correttore interno del colore e obiettivo da uno switcher ATEM. Usando uno switcher ATEM Mini, il connettore HDMI emette un segnale 1080 ed è compatibile con tutte le funzioni di controllo.
Registrando in Blackmagic RAW sui drive USB-C esterni, la camera si trasforma in una cinepresa della qualità di Hollywood. Grazie a una serie di fori di montaggio, Blackmagic Micro Studio Camera 4K G2 si può installare ovunque.
Technical characteristics
Camera features
- Effective sensor size: 17.78 x 10 mm
- Lens mount: Active MFT mount
- Lens control: Iris, focus, zoom on supported lenses
- Dynamic range: 13 stops
- Dual native ISO: 0 dB and 18 dB gain
- Sensitivity at 0 dB gain: f 11 with 3840 x 2160p 59.94, f 12 with 3840 x 2160p 50 at 2,000 lux with 89.9% reflectance
- Signal to noise ratio: 63 dB for 3840 x 2160p
- Shooting resolutions: 3840 x 2160p up to 60
- Frame rates: 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 frames per second
- Off-speed frame rates: Up to 60 fps in 3840 x 2160p
- Focus: Auto focus available using compatible lenses
- Metadata support: Automatically populated lens data from electronic Micro Four Thirds lenses
- Embedded metadata: Camera settings, motion sensor data, slate data, 3D LUT in Blackmagic RAW files
- Mounting options: 1 x 1/4 inch top, 3 x 1/4 inch bottom
Connections
- SDI video inputs: 1 x 12G-SDI micro BNC
- SDI video outputs: 1 x 12G-SDI micro BNC
- SDI rates: 3G, 6G, 12G
- HDMI video outputs: 1 x HDMI type A output
- HDMI output resolution: 1920 x 1080p 60
- Analog audio input: 1 x 3.5 mm stereo input (also usable for Time Code)
- Reference inputs: program SDI input
- SDI audio output: 2 channels of program audio embedded in 3G / 6G / 12G-SDI
- HDMI audio outputs: 2 channels 48 kHz and 24 bit
- Remote control: remote camera control over SDI, HDMI or USB Ethernet with suitable adapter
- Computer interface: 1 x USB Type‑C 3.1 Gen 1 (up to 5 Gb/s) expansion ports for external recording and focus / zoom demand connection. Software updates using USB‑C Port
Audio
- Microphone: integrated stereo microphone
- Built-in speaker: none
Standards
- HD video standards: 1920 x 1080p 23.98, 1920 x 1080p 24, 1920 x 1080p 25, 1920 x 1080p 29.97, 1920 x 1080p 30, 1920 x 1080p 50, 1920 x 1080p 59.94, 1920 x 1080p 60
- HD interlaced standards: 1920 x 1080i 50, 1920 x 1080i 59.94, 1920 x 1080i 60
- Ultra HD video standards: 3840 x 2160p 23.98, 3840 x 2160p 24, 3840 x 2160p 25, 3840 x 2160p 29.97, 3840 x 2160p 30, 3840 x 2160p 50, 3840 x 2160p 59.94, 3840 x 2160p 60
- SDI compliance: SMPTE 292M, SMPTE 424M, SMPTE 425M level A and B, SMPTE 2081-1, SMPTE 2081-10, SMPTE 2082-1, SMPTE 2082-10
- SDI audio sampling: elevision standard sample rate of 48 kHz and 24‑bit
Media
- Media interface: 1 x USB-C 3.1 Gen 1 expansion ports for external media for recording Blackmagic RAW
- Media format: Can format media to ExFAT (Windows/Mac) or HFS+ (Mac) file systems
Supported codecs
- Blackmagic RAW Constant Bitrate 3:1, 5:1, 8:1, 12:1, Constant Quality Q0, Q1, Q3, Q5
Storage features
- Storage type: 1 x USB‑C 3.1 Gen 1 expansion ports for external media
- Recording formats: Blackmagic RAW 3:1, 5:1, 8:1, 12:1, Q0, Q1, Q3 and Q5 in Ultra HD 3840 x 2160 at the selected frame rate
- Storage rates: storage rates based on 30 frames per second. 3840 x 2160p 30 fps — 3:1: 127 MB/s, 5:1: 77 MB/s, 8:1: 48 MB/s, 12:1: 32 MB/s, Q0: 96 to 190 MB/s, Q1: 64 to 153 MB/s, Q3: 43 to 109 MB/s, Q5: 26 to 64 MB/s
Control
- 5 control buttons including Set, Up, Down, Menu, and Power
- External control: Blackmagic Zoom Demand and Blackmagic Focus Demand for controlling your camera and lens from tripod handles. Blackmagic Control Protocol over SDI and HDMI for external control when used with a compatible ATEM switcher with ATEM Software Control or ATEM Camera Control Panel. Includes control of some camera settings, focus, iris and zoom with compatible lenses, color corrector, tally and record start and stop to external media via USB expansion port
Network management
- NTP support: Network Time Protocol support allows you to sync the time on your camera, whenever connected to a network with any NTP server of your choice
- Web media manager: using a browser connected over Ethernet, web media manager allows you to access, browse, download and delete files from any drive connected to the camera
- FTP: download files from any drive attached to your camera using FTP
- SMB: file sharing via SMB
Color corrector
Tally
- 1 x front facing for talent
Software included
- Blackmagic Camera Setup for Mac and Windows
Operating systems
- Mac: 13.0 Ventura, 14.0 Sonoma or later
- Windows: 10 and 11
Power requirements
- Power supply: 1 x external 12 VDC 36 W
- Power inputs: 1 x 12 VDC locking 5.5 mm barrel connector
- Power usage: 18 to 25 W
Optional accessories
- Accessories: Blackmagic PYXIS Monitor, Blackmagic Focus Demand, Blackmagic Zoom Demand, ATEM Mini switchers, ATEM SDI switchers, ATEM Television Studio switchers, ATEM Constellation switchers, Blackmagic Video Assist, LP-E6 Battery, Micro BNC Cables
Environmental specifications
- Operating temperature: 0 to 40 °C
- Storage temperature: -20 to 45 °C
- Relative humidity: 0% to 90% non-condensing
Physical specifications
- Dimensions: 8.4 x 6.95 x 6.58 cm
- Weight: 0.3 kg
What’s included
- Blackmagic Micro Studio Camera 4K G2
- Turret dust cap
- External 12 VDC power supply with locking connector and international socket adapters
- Welcome wallet with QR code for software download
