NC4FD-LX-BAG - 4 pole female XLR receptacle, solder cups, black metal housing, silver contacts, DLX series

€ 13,32

SKU: NC4FD-LX-BAG

Ask for availability To find out the price dedicated to you, follow the link and register on audioeffetti.com. Our office will contact you as soon as possible.

4 pole female XLR receptacle, solder cups, black metal housing, silver contacts, DLX series

4 pole female receptacle, solder cups, black metal housing, silver contacts, DLX series. The DLX series features a compact all metal housing with an ingenious duplex ground contact, which offers excellent RF protection and shielding.

Features & Benefits

All metal housing offers best overall RF protection and electromagnetic shielding
Duplex ground contact for excellent contact integrity between chassis and cable connector
Female contact incorporates a solder barrier to prevent solder running into the contact mating area
Larger solder contacts for easier termination
Optional connection to easily join pin1 to chassis ground
D-style housing provides installation compatibility with industry standard D mounting dimensions

Product

Title NC4FD-LX-BAG
Connection Type XLR
Gender female

Electrical

Capacitance between contacts ≤ 7 pF
Contact resistance ≤ 5 mohm
Dielectric strength 1,5 kV_DC
Insulation resistance > 10 Gohm (initial)
Rated current per contact 10 A
Rated voltage < 50 V

Mechanical

Insertion force ≤ 20 N
Withdrawal force ≤ 20 N
Lifetime > 1000 mating cycles
Wiresize max. 1.5 mm²
Wiresize max. 16 AWG
Wiring Solder contacts
Locking device Latch lock
Chassis shape D

Material

Contact plating 2 µm Ag over 2 µm Ni
Contacts Brass (CuZn39Pb3)
Insert Polyamide (PA 6.6 30 % GR)
Locking element Steel Ck67
Shell Zinc diecast (ZnAl4Cu1)
Shell plating Black chromium

Environmental

Flammability UL 94 HB
Standard compliance IEC 61076-2-103
Protection class IP 40
Solderability Complies with IEC 68-2-20
Temperature range -30 °C to +80 °C
