hd M8-32 - PointSource stick: 8x 2 broadband drivers, passive, 200W, 100°x30°, 32 Ω, wallmount, cable inlet wall bracket not included, see accessories pages
The hd M8-32, thanks to its eight 2″ wide-band drivers, is perfect for near field and/or vocal applications. This 32Ω unit can be powered by hd system amplifiers, or any power amplifier with DSP. Due to its 10° x 30° emission, this speaker is the ideal solution for diffusion applications in restaurants, conference rooms or theaters. The hd M8-32 can be flexibly and easily installed permanently, even if it can also be used as a mobile device. To orient its sound output in any environment, the cabinet can be easily swiveled and tilted using the discreet ball joint wall mount. Otherwise the unit can be attached with the L-angle wall mount extremely close and unobtrusive to the surface to be fixed. Internal terminal block connections ensure a tool-free and quick connection of the loudspeakers. For optimum integration to the room style, the loudspeaker can be customized in all RAL colors as well with custom lengths. If wall mounting is not possible, the speakers can be used with the optional 35mm flange base plate and NL4 speaker connector socket on a tripod.
Principle Point Source * Transducers 8x 2″ fullrange drivers * Crossover active at 130 Hz * Power handling capacity (RMS/Peak) 200 W / 280 W * Frequency range 160 Hz – 20 kHz * Sensitivity (1 W / 1 m) 95 dB * SPLmax 119 dB * Nominal dispersion angle horizontal 100° x vertical 50° * Nominal impedance 32 Ohms * Connectors 1x clamp connection inside * Dimensions (W x H x D) 80 x 1000 x 78 mm * Weight 5 kg * Enclosure Powder-coated aluminium profile black, Steel grille with acoustic foam, Clamping terminal inside, Cable insert at the back, incl. 2x M6 nuts * Options NL4 speaker connector, 35 mm flange + NL4, wall mount, weather protection, 100V transformer, RAL color, special custom length
