AMX-4120 - 120 W 4 zone mixing amplifier with integrated media player, 100 V line, DC 24 V power supply, microphone call station and compatible wall plate

€ 1.405,70

SKU: 02823

Available

1 Available Available in Italian warehouse

100 Available items Available in European warehouse

Add to cart To find out the price dedicated to you, follow the link and register on audioeffetti.com. Our office will contact you as soon as possible.

120 W 4 zone mixing amplifier with integrated media player, 100 V line, DC 24 V power supply, microphone call station and compatible wall plate

The Rondson AMX-4120 integrated amplifier / mixer is designed to handle up to four audio zones with an output power of 120 W per channel.

It features a media player with FM / DAB tuner, MP3 / USB / SD / Bluetooth player, so as to offer a wide range of options for audio playback. It has 3 Combo MIC / line inputs with switchable Phantom power, an AUX input on RCA connectors and bass / treble tone controls on the rear panel for each input.

The rear panel also features 4 remote control ports and 2 remote MIC ports on RJ45 connectors for controlling the AMX-4B wall panel and selecting the AMX-4A zone. There are also 2 x L/R RCA outputs + monitor output and 4 loudspeaker outputs (for 4 different zones) on Euroblock connectors. There is also a dry contact for PA interruption.

The amplifier includes protections against overload, short circuit and overheating, ensuring reliability and safety.

The AMX-4120 is ideal for commercial and professional applications requiring flexible audio management.

Technical characteristics

Power: 4 x 120 W
Built-in sources: FM / DAB tuner, MP3 / USB / SD / Bluetooth
Power supply: 230 V_AC50/60 Hz, 24 V_DC
Loudspeaker output: 4 channels, 100 V, 8 - 16 ohms
Inputs / sensitivity:
- MIC / line 1 - 3: 60 dB – 16 dB / 20 kohm balanced
- Line 1: 20 dB + dB / 20 kohm balanced
- 2 x RJ45: 0 dB / 600 ohm balanced
Output level: 0 dB / 600 ohm balanced
Frequency response: 70 Hz – 20 kHz (± 3 dB)
SNR: > 80 dB
Consumption: 550 W
THD: < 0.5%
Tone adjustment: bass / treble tone controls on the rear panel for each input
Protection and cooling: fan, thermal protection, overload and short circuit
Dimensions (W x H x D): 48.4 x 8.8 x 40.5 cm
Weight: 6.3 kg
