MOJO2200curve - 1600 W high output curve array system with 12" subwoofer

1600 W high output curve array system with 12" subwoofer

High efficiency PA speaker, consisting of a column and an active subwoofer. This new system uses a curved array architecture that provides controlled and optimized diffusion for a sound pressure of 128 dB_SPL.

With a total of 12 speakers (3 x 5" neodymium drivers and 9 x 1" tweeters), the satellite has been specially designed to achieve an effective dispersion of 100° horizontally and 70° vertically.

The bass is provided by a powerful 12" long excursion woofer mounted in bass-reflex. The cabinet houses a 500 WRMS Class-D amplifier equipped with all protections, a 4-input mixer with Bluetooth TWS and a powerful DSP that offers the possibility to adjust the sound according to your wishes.

The connection between the subwoofer and the array is made thanks to a pneumatic coupling bar which allows for effortless height adjustment and also ensures the electrical connection between the amplifier and the satellite.

Technical characteristics

Column

• Power: 300 W_RMS - 600 W max.
• Nominal impedance: 6 ohm
• Mid-woofer: 3 x 5" neodymium
• Tweeter: 9 x 1"
• Dispersion (H x V): 120° x 70°
• Connector: insert into housing
• Dimensions: 188 x 517 x 243 mm
• Net weight: 8 kg

Subwoofer

• Power: 500 W_RMS - 1000 W max.
• Nominal impedance: 4 ohms
• Woofer: 1 x 12"
• Dimensions: 366 x 625 x 541 mm
• Net weight: 27 kg

Complete system

• Frequency response: 38 - 18,000 Hz
• SPL max. (@ 1 m): 128 dB

Amplifier module

• Low section: 1 x 700 W_RMS / 1400 W max. at 6 ohm
• Mid/high section: 1 x 300 W_RMS / 600 W max. at 4 ohm

Inputs

• CH1: 1 x XLR / line jack / microphone Combo
• CH2: 1 x XLR / line MIC / jack Combo
• CH3: 1 x line jack
• CH4/5: 1 x RCA L/R line + Bluetooth input

Input impedances

• Micro 1 & 2: balanced 40 kohm
• Line 1 & 2: balanced 10 kohm
• Line 3: balanced 20 kohm
• Line 4 & 5: unbalanced 5 kohm

Outputs

• 1 insert on the top of the housing for the stellite
• 1 x balanced XLR MIX OUT for output to another system
• 2 x XLR LINE OUT balanced for the CH1 and 2

DSP

• 24 bit (1 in 2 out)
• EQ / presets / low cut / delay / Bluetooth TWS
• Adjustment of levels on each channel + Master
• Adjusting the level of the cabinet
