D7-330 DIAMOND 7 - 30 motorised fader lighting console, 30 playback encoders, 3 x 14" touch displays, 1 x 4.3" capacitive touch screen

30 motorised fader lighting console, 30 playback encoders, 3 x 14" touch displays, 1 x 4.3" capacitive touch screen

Diamond D7-330 is the latest addition to the renowned Diamond series of lighting consoles produced by Avolites. This creative console, which is placed just below the Diamond 9 in the hierarchy of Avolites products designed for visual designers and which incorporates many of their technical and design solutions, has 30 faders and 3 x 14" touch displays.

The control surface is well designed, flexible and extremely functional; this careful study of every detail allows light designers to create, program and control their lighting setups with ease and immediacy. Buttons caps, faders caps, encoder knobs, encoder wheels and level wheel are made exclusively for this console.

Let's see the main features of the control surface:

• 3 x 14" capacitive touch main screens, 850 nits, 1920 x 1200 pixels, with adjustable brightness
• 1 x 4.3" capacitive touch screen, 850 nits, 800 x 480 pixels for macro and workspace, with adjustable brightness
• 30 touch-sensitive motorized faders, with fader cap
• Dual, motorized, touch-sensitive master cue list faders with 9 control buttons
• RGB fader indicator
• 30 ultra-high resolution touch-sensitive playback encoders with push function
• RGB encoder indicator
• 120 C&K playback function buttons with positive haptics for timing designer key cap
• Independent paging for each playback section
• 10 backlit Macro / Executor keys and 10 soft Macro buttons with legend on the Macro screen
• Programming buttons all RGB backlit, short travel Cherry MX low profile switches
• 5 custom RGB backlit optical attribute encoders
• Dedicated level wheel and on-screen level indication
• Fully custom backlit QWERTY keyboard (in drawer)
• Supports an additional external touchscreen via Display Port at 1920 x 1080 pixels

On a construction level we find an uncompromising construction: to begin with, the entire structure is made of aluminum to reduce weight. The clamshell design LCD panel allows for reduced transport size, with locking mechanism and screen panel articulation adjustable in 6° steps from – 90 to 155° from vertical. All screens are flush mounted. There is also a comfortable arm rest.

The console supports animation-based generative pixel mapping, Quicksketch labeling for extreme customization, powerful multi-user networking with any other Titan console, advanced Cue Lists with support for macros, tracking, autoloads, time code and more. DMX capacity is synergy-ready and can be expanded with Titan Net processors to increase DMX channel capacity.

Technical characteristics

• Custom AMD processing hardware to get the best processing performance and cooling with the addition of features like industry standard XLR connectors for networking and protected outlets
• 4 x isolated DMX outputs via 5 pin XLR connectors
• Ethernet switch with 4 x Neutrik XLR on the Primary network port
• Secondary network port
• MIDI in, Loop and OUT port in DIN 5
• Trigger input on ¼” jack
• GPIO with 4 inputs and 4 outputs on 15-pin D-sub connector
• Audio input for 7 band triggers, via 3-pin XLR with transformer isolation
• SMPTE RTU Time Code in and Loop OUT via 3-pin XLR with transformer isolation
• Rear work light
• Desk light above LCD screen
• 2 x 3 pin XLR desk light sockets
