An extremely powerful laser projector, designed for professional entertainment lighting applications, including stages, concerts, shows and TV productions, music festivals, discos, DJ sets, clubs, nightclubs, bars, private parties, service and rental.
The Laserworld PL-10.000RGB MK3 is equipped with diodes and has a good white balance, linear color fading behavior and high visibility. The Laserworld PL-10.000RGB MK3 units have a built-in network DAC for Showcontroller and Showeditor, but can also be controlled with any ILDA laser control software such as Pangolin Quickshow, Pangolin Beyond, LSX, Lasergraph DSP, etc. via external ILDA interface. They also have a built-in memory with preset patterns, which can be easily activated via DMX / Art-Net and auto mode. The Laserworld PL-10.000RGB MK3 is equipped with a built-in ShowNET network interface and free laser show software.
The Laserworld PL-10.000RGB MK3 has a beam diameter of approximately 5.5 mm and a divergence of 1.0 mrad. The guaranteed output power at the aperture is 10,000 mW and the individual source powers are: 3000 mW / 638 nm (red), 3000 mW / 520 nm (green), 4500 mW / 450 nm (blue).
The fast scanners operate at 40 kpps @ 8° ILDA and can perform a max. scan angle of 50°. The projector is completely assembled in a sealed housing and is cooled by external cooling fins (bottom). This reduces maintenance to a minimum.
On the back of the unit are the potentiometers for the color settings, so that the color balance can be quickly adjusted. The safety limit of the scan can also be set on the back of the laser.
The Laserworld PL-10.000RGB MK3 features an integrated ShowNET network interface with free laser control software included. Start programming your professional laser show with the intuitive Showeditor laser show software that comes free of charge with every new Laserworld PL-10.000RGB MK3. The Showcontroller software is also supported and can be purchased additionally. The integrated ShowNET allows direct input via ILDA and LAN. In addition to DMX, individual frames can be triggered via Art-Net. You can play back custom frames and shows from an integrated SD card (included in delivery), even in stand-alone mode.
Technical characteristics
