Electric chain hoist, 250 kg, 4 m/min, 5 m of galvanized chain, chain bag
Divo ONE 250-5m is a robust and reliable electric chain hoist designed to lift heavy loads up to 250 kg even in complex environments. It uses a 5 m long galvanized chain and a chain bag.
It features an aluminum body, a chain guide system designed to reduce jamming, double swivel hook. Complies with the IGVW SQP2 guideline.
Main features
- Very robust structure
- Compact design
- Precision in movements
Areas of use
- Show biz, entertainment
- Television
- Technical installations
Technical characteristics
- Load capacity: 250 kg
- Chain lenght: 5 m
- Lifting speed at 50 Hz: 4 m/min
- Operating voltage: 400 V 50 Hz
- Degree of protection: IP 55 DIN 40050
- Motor power at 50 Hz: 0.18 kW
- FEM CLASS: 2m
- DC braking system: 2 brake
- Noise level: < 67.5 dB (full load)
- Loading wheel: 5 hpockets
- RUD load chain: 4 x 12 mm
- Number of chains: 1
- Chain weight: 0.36 kg/m
- Control type: direct control
- Connector type / Red plug: 400 V CEE 16 A - 3P+E
- Reverse use: allowed
- Safety factor: 8:1
- Handles: optional
- External load cell: optional
- Machine body weight: 11 kg
