MTP3.9-7.8 - Transparent display, indoor & outdoor, 3500 - 4000 nit, 1920 - 3840 Hz, IP 65, 1000 x 500 mm, 7.5 kg

Transparent display, indoor & outdoor, 3500 - 4000 nit, 1920 - 3840 Hz, IP 65, 1000 x 500 mm, 7.5 kg

The new transparent Yes Tech display in the P3.9-7.8 version has an asymmetric pitch of 3.9 x 7.8 mm which allows it to achieve a transparency of over 40% with a white balance brightness of 3500 - 4000 nits and a max. refresh rate of 3840 Hz. The special ultra-light frame in die-cast aluminium, anti-corrosion, resistant to humidity, waterproof, with a base of 1 m and a height of 50 cm, makes it invisible in all scenographic installations and events. Adopting die-cast aluminum frame, the display is light and thin, which makes the whole LED wall more convenient to hang (safety hanging height is 10 m).

The protection level IP65 and is suitable for various indoor and outdoor scenarios.

Featuring a high refresh rate, this display offers exceptional visual quality. The most interesting aspect is given by the possibility of changing the visual mode from transparent or non-transparent (optional) with a "click".

Furthermore, it supports front and rear maintenance and adopts a magnetic / screw fixing system which makes front maintenance even easier. The integrated control box design greatly improves installation and maintenance efficiency. The quick lock with large handle makes installation by one person possible.

The fast lock mechanics guarantee the possibility of making positive or negative curves with a span of 20° (±10°) using a high precision arc lock, while by simply moving the side connector you can create perfect 90° corners.

All these features make MTP3.9-7.8 the new reference for transparent LED walls for rental use.

Benefits for users

• Transparency
• High brightness, which allows them to be used even in very bright environments, both indoors and outdoors (IP 65)
• Lightweight, each cabinet weighs only 7.5 kg with a surface of 100 x 50 cm

Application areas

• Advertising installations in shops, shopping centers
• Outdoor discos
• Design and architecture
• Artistic installations in museums and art galleries

Technical characteristics

• Cabinet size: 1000 × 500 x 83 mm
• Module size: 500 x 125 mm
• Cabinet weight: 7.5 kg
• Cabinet area: 0.5 m²
• Resolution (W x H): 256 x 64
• Pixel pitch: 3.9 – 7.8 mm
• Module quantity per cabinet (W x H): 2 x 4
• White balance brightness: 3500 - 4000 nit
• Color temperature: 6400 - 10,000 K adjustable
• Supply voltage: 100 – 240 V_AC 50/60 Hz
• Power supply: South Creative Technology
• IP grade: IP 65
• Physics density: 32,768 dot/m²
• Power consumption: 500 + 15% W/m²
• Average power consumption: 200 W/m²
• Brightness: 3500 - 4000 cd/m²
• Driving method: constant drive
• Scanning method: 1/8 scan
• LED encapsulation: SMD1820, black shell white face LEDs
• IC DP3265
• Visual angle (H / V): 160° / 140°
• Receiving card: B6S
• Control system: Novastar
• Frame frequency: 50 & 60 Hz
• Refresh frequency: 1920 - 3840 Hz
• Communication mode: CAT5
• Life span: 80,000 h
• Transparence: 40%
• Working / storage temperature: -20 to 45 °C / -30 to 60 °C
• Working / storage humidity: 10 - 90% / 10 - 90% RH (no condensation)
• Product certification: CE, FCC, ETL
