The Yes Tech MG9 P2.9 Cube LED display allows you to create LED walls for the rental market or installations and represents an updated version of the flagship model of the Chinese manufacturer, the MG7S Cube. In particular, the unique structural design of the cabinet allows you to create cubic or 90° angle LED walls, making the MG9 series even more creative.
Suitable for an indoor or outdoor operating environment, thanks to the IP65 certification which makes it suitable to withstand atmospheric agents, it is available in 2.9 / 3.9 / 5.9 mm pitches. The dimensions of the cabinet remain those of the MG7S, 500 x 500 mm, with a depth of 73 mm and a weight of only 6.6 kg. Each cabinet houses 4 modules of 250 x 250 mm.
The brightness is adjustable between 800 and 5500 nit based on the ambient light, the white balance brightness before calibration is 3500 - 3800 nits, the horizontal / vertical viewing angle is 160° and the contrast in the order of 10,800:1. And, still in terms of performance, Yes Tech MG9 P2.9 features a high refresh rate of 3840 - 7680 Hz obtained thanks to the new IC DP3254.
The resistance of the 1516 LED lamp has been significantly improved, now reaching 100 N against the 26 / 30 N of the 1921, obtained thanks to a greater LED edge margin, which therefore entails a greater anti-shock capacity. The anti-collision design also includes the use of protective corners that effectively protect the LEDs on the edge of the cabinet.
The visual effect is also excellent. The U-shaped mask avoids distortion or color blocking and offers wider coverage.
At the cabinet level, heat dissipation has been improved: a dual dissipation system uses an aluminum backplane and a thermal balance system to evenly distribute the heat of the LED lamp and IC. The integrated back cover design and heat dissipation function greatly increase the heat dissipation area.
More complexly shaped installations will no longer be a problem with this display: the special MG connector can be customized to an angle between ±5° on this 2.9 pitch model, allowing you to create curved, S-shaped and shaped of ring LED walls. For creative shapes, the cabinet can be combined with Yes Tech special shapes to create particular letters, numbers, geometric figures, etc.
MG9 P2.9 can be used for a multitude of applications, for example in stadiums as well as at concerts (indoors or outdoors), in award ceremonies, as a sky curtain, to create portals in trade fair stands and as a dance floor (using the patented MG mask). And speaking of this latest application, the anti-fatigue performance is almost fivefold, with a maximum load-bearing capacity of 4.6 T!
User benefits
Areas of use
Technical characteristics
