500 x 500 mm P3.9 MG7S LED display, SMD1515, copper wire, black shell LED, indoor and outdoor, for rental use. This display uses black shell 1515 LEDs with a customised copper wire architecture, designed to meet the needs of mixed-use products.
The unique structural design of the cabinet allows you to create cubic or 90° corner LED walls, making the MG series even more creative. MG7S cube can also be connected to other MG7S series cabinets (including the creative extension series) via special connectors to obtain more creative shapes such as numbers, letters and graphics and meet the changing application scenarios in the rental market.
When adjusting the brightness from 4500 to 1000 nits, the relatively small range keeps the RGB of the LEDs within the optimal response range. The maximum pixel density of the MG7S P3.9 is 65536 dots/m2, the best pitch for both indoor and outdoor use. In terms of pixel pitch, the MG7S P3.9 offers multiple advantages, with uniform HD images and an optimised ratio between the size of the venue and the screen, as well as a more comfortable viewing angle for the public.
The MG7S P3.9 uses black shell 1515 LEDs. Compared to the white 1921 LEDs of other competing products, the 1515s are smaller and ensure better edge protection, anti-impact performance and greater stability. Additionally, this LED wall module has passed rigorous protection tests and is IP65 certified, completely preventing the entry of dust and water. The grey IC with a high refresh rate, combined with a high-performance control system and HDR technology, allows for impressive color expression. When the LED wall is in front of a camera, the 1/11 scanning mode provides smoother captured images.
The MG7S P3.9 is based on a new totally modular design, with each cabinet made up of three independent parts: module, driver and power supply. Inside, the cabinet is wireless, with safe and stable signal and power transmission. Furthermore, maintenance is very quick and easy.
Included are:
Cube-Cube connectors are optional.
User benefits
Areas of use
Technical characteristics
| Module | |
| LED encapsulation | 1515 black shell LED |
| Pixel pitch | 3.9 mm |
| Module resolution (W x H) | 64 x 64 |
| Module size | 250 x 250 mm |
| Cabinet | |
| Module quantity per cabinet (W×H) | 2 x 2 |
| Cabinet resolution (W x H) | 128 x 128 |
| Cabinet size | 500 x 500 x 73 mm |
| Cabinet area | 0.25 m2 |
| Weight | 6.5 kg/cabinet |
| Pixel density | 65,536 dot/m2 |
| IP grade | IP65 |
| White balance brightness | 4200 - 4500 nit |
| Color temperature | 6500 - 10,000 K adjustable |
| Horizontal viewing angle | 160° |
| Vertical viewing angle | 160° |
| Contrast ratio | 6000:1 |
| Electrical parameters | |
| Power consumption | 600 / 200 W/m2 |
| Working voltage | 100 - 264 VAC 50/60 Hz |
| Processing performance | |
| Driving method | constant drive |
| Scanning method | 1/11 |
| Driving IC | DP3265 |
| Receiving card | Nova A5S+ |
| Refresh frequency | ≤ 3840 Hz |
| Control system | Nova Star |
| Usage parameter | |
| Life span | 80,000 h |
| Working / storage temperature | -20 to 45 °C / -30 to 60 °C |
| Working / storage humidity | 10 - 90% / 10 - 90% RH (no condensation) |
| Communication mode | CAT5 |
| Certification | CE FCC ETL |
