98" 4K (3840 x 2160), 500 cd/m2 professional large format display (LFD) for reliable 24/7 operation, IPS technology, FailOver, SmartPlayer, CMND & Control
The 98BDL4511D/27 is a professional 98" 4K UHD LFD designed for intensive 24/7 use.
Its 500 cd/m² brightness and IPS panel deliver vivid colors and a wide viewing angle, while FailOver technology ensures content continuity even in the event of a problem with the main source. SmartPower optimizes energy consumption, reducing operating costs by up to 50%, and SmartPlayer lets you manage media playlists directly from a USB stick.
The CMND & Control system allows you to monitor and control your display network via LAN, making centralized management simple and effective. Furthermore, the integrated OPS slot allows the addition of compatible media players, transforming the display into an all-in-one solution for digital signage.
In terms of connectivity, the display offers multiple inputs, including HDMI 2.0, DisplayPort, DVI-I, USB, and audio jacks, and is ready for external control via RS232, RJ45 and infrared. Designed for professional environments, this LFD combines high performance, operational flexibility, and smart management.
User benefits
- Operational continuity guaranteed with FailOver technology in the event of a power failure
- Energy cost reductions of up to 50% with the SmartPower function
- Easy centralized management with the CMND & Control system via LAN
- OPS Slot
Areas of use
- Meeting rooms
- Retail
- Digital Signage
Technical characteristics
Picture/display
- Diagonal screen size: 247.6 cm
- Diagonal screen size: 97.5"
- Aspect ratio: 16:9
- Panel resolution: 3840 × 2160
- Brightness: 500 cd/m2
- Display colors: 1.07 billion
- Contrast ratio (typical): 1300:1
- Dynamic contrast ratio: 500,000:1
- Response time (typical): 8 ms
- Viewing angle (horizontal): 178°
- Viewing angle (vertical): 178°
- Panel technology: IPS
Connectivity
- Audio output: 3.5 mm mini-jack
- Video input: DisplayPort 1.2, DVI-I, 2 × USB 2.0, 3 × HDMI 2.0
- Audio input: 3.5 mm mini-jack
- Other connections: OPS
- Video output: DisplayPort 1.2, HDMI 2.0
- External control: RS232C (IN/OUT) 2.5 mm mini-jack, RJ45, IR (IN/OUT) 3.5 mm mini-jack
Convenience
- Placement: landscape (24/7), portrait (24/7)
- Screen saving functions: pixel shift, low bright
- Keyboard control: hidden, lockable
- Signal loop through: RS232, DisplayPort, HDMI, IR loopthrough
- Energy saving functions: Smart Power
- Network controllable: RS232, RJ45
Sound
- Built-in speakers: 2 × 10 WRMS
Power
- Mains power: 100 - 240 VAC 50/60 Hz
- Consumption (typical): 355 W
- Consumption (max): 605 W
- Standby power consumption: < 0.5 W
- Energy label class: G
Supported display resolution
- Computer formats: from 640 × 480 @ 60 Hz up to 3840 × 2160 @ 60 Hz
- Video formats: 480i/p, 576i/p, 720p, 1080i/p, 2160p
Operating conditions
- Altitude: 0 - 3000 m
- Temperature range (operation): 0 to 40 °C
- Temperature range (storage): -20 to 60 °C
- Humidity range (operation): 20 - 80% RH (no condensation)
- Humidity range (storage): 5 - 95% RH (no condensation)
- MTBF: 50,000 hours
Multimedia applications
- USB playback video: MPEG, H.264, H.263, H.265
- USB playback picture: JPEG, BMP, PNG
- USB playback audio: AAC, MPEG, HEAAC
Miscellaneous
- On-Screen display languages: Arabic, Danish, Dutch, English, Finnish, French, German, Italian, Japanese, Norwegian, Polish, Portuguese, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, Turkish
- Warranty: 5 years
- Regulatory approvals: BSMI, CB, CCC, CE, CECP, EAC, EMF, ETL, FCC Class A, PSB, RoHS, VCCI
Accessories
- Included: quick start guide, RS232 daisy-chain cable, Philips logo, USB cover and screw, AC switch cover, 3 × wire clampers, AC power cord, IR sensor cable (1.8 m), remote control & AAA batteries, RS232 cable
Dimensions & weight
- Dimensions: 219.32 × 124.82 x 8.79 cm (wall mount) / 9.79 mm (handle)
- Bezel width: 16.0 mm (T / R / L / B)
- Wall mount: 1000 × 400 mm
- Weight: 90.52 kg
