HDMI to USB 3.0 capture and recording device, 4K 60 HDR pass‑through, 1080p USB streaming, UAC / UVC standards supports, audio capture from HDMI or analogue input
HDMI capture device with USB 3.0 output designed to record or stream video content up to 1080p, while maintaining HDMI pass-through output up to 4K @ 60 Hz 4:4:4 HDR.
HDMI sources up to 1080p are captured without scaling, while 4K signals are automatically converted to 1080p to ensure compatibility with streaming and recording software.
Thanks to video timing stabilization technology, the USB stream remains stable even in the event of interruptions or disconnections from the HDMI source. Audio can be captured from both the HDMI input (LPCM 2.0) and the 3.5 mm analog input, selectable via software.
The device is compatible with UAC and UVC standards, supporting most streaming and video conferencing software, including OBS, Zoom, Teams, and many other applications on Windows, macOS, and Linux.
Power is supplied directly via USB 3.0, without the need for external power supplies.
Main features
- HDMI input and output with HDR, 3D, and 4K @ 60 Hz support, DVI 1.0 compatible
- HDCP 2.2 and HDCP 1.x compatible
- Video support up to 4K UHD at 18 Gbps (4K @ 50/60 Hz 4:4:4, 8-bit) input and output
- Deep Color support up to 12-bit
- 10-bit and 12-bit HDR support input and output
- Automatic scaling of 4K to 1080p signals for USB capture
- Direct power supply via USB 3.0 (requires USB 2.0 Y-cable)
- Video timing stabilization function to ensure a stable USB stream even with intermittent signals
- Uncompressed USB 3.0 capture up to 1080p with LPCM 2.0 audio
- Compressed USB 2.0 capture Minimum MJPEG up to 1080p with LPCM 2.0 audio
- HDMI digital audio capture (LPCM 2.0) or analog audio via 3.5mm stereo input
- Compatible with UAC (USB Audio Class) and UVC (USB Video Class) standards
- Support for most streaming and video conferencing software
- Compatible with OBS (Open Broadcaster Software) for Windows, macOS, and Linux
- Availability of controllable functions varies depending on the capture software used
User benefits
- Professional video quality with stable and seamless 1080p USB capture
- Video timing stabilization prevents blocking, freezing, or loss of flow even with unstable or intermittent sources
- Universal compatibility with streaming, recording, and video conferencing software
- Flexible audio capture from HDMI or analog input
- Direct power supply via USB 3.0 without external power supplies
- Full support for OBS on Windows, macOS, and Linux
- Automatic management of the scaling
Areas of use
- Live streaming on platforms such as YouTube, Twitch, Facebook Live, and LinkedIn Live
- Gameplay recording from consoles or PCs with 4K pass-through for high-quality content monitoring
- Video production, tutorials, online courses, and training content
- Video conferences, webinars, and corporate presentations
- AV content capture for archiving, editing, or digital distribution
- Digital Signage
- Control or monitoring systems
Technical characteristics
Interfaces
- Input ports: 1 x USB 3.0 Type‑B (power & data), 1 x HDMI, 1 × 3.5 mm stereo mini‑jack
- Output ports: 1 x HDMI, 1 x USB 3.0 Type‑B (stream data, power & data)
Video
- HDMI compliance: HDMI 2.0 (DVI 1.0)
- HDCP compliance: HDCP 2.2 bypass
- Input signal type: 4K @ 60 8‑bit YUV 4:4:4, HDR 12‑bit
- Output signal type: 4K @ 60 8‑bit YUV 4:4:4, HDR 12‑bit
- Max. input resolution: 4096 x 2160p @ 60 Hz
- Max. output resolution: 4096 x 2160p @ 60 Hz
- N.B. according to HDCP regulations, HDCP‑protected content cannot be streamed
Audio
Power
- Power supply: powered by USB
- Power consumption: 7.15 W
Field firmware update
Enclosure
- Chassis material: metal
- Chassis colour: black
- Dimensions (W x H x D): 12.8 x 2.5 x 10.8 cm (case only)
- Dimensions (W x H x D): 12.8 x 2.5 x 11.7 cm (all inclusive)
- Weight: 364 g
