Teranex Express - 12G-SDI real time up, down, cross and standards converter

12G-SDI real time up, down, cross and standards converter

Teranex Express di Blackmagic Design è il primo convertitore di standard di trasmissione SD, HD e Ultra HD in tempo reale al mondo!

Con algoritmi avanzati e brevettati, Teranex Express vi offre 1089 conversioni visivamente trasparenti e di alta qualità in SD, HD e Ultra HD up, down e standard a 10 bit, che sono richieste dai maggiori broadcaster e studios di tutto il mondo.

Dispone anche di deinterlacciamento di alta qualità, riduzione del rumore, rilevamento automatico della cadenza, rimozione e correzione anche con contenuti già editati, scaling regolabile e conversione delle proporzioni, il tutto con conversione completa di Time Code e audio multicanale.

Caratteristiche principali

• Conversioni di standard broadcast in tempo reale
• 1089 conversioni di standard e formato distinte
• Conversioni da / a qualsiasi segnale, formato e frame rate
• 12G-SDI per tutti i formati SD, HD e Ultra HD fino al 2160p 60
• Conversione di Time Code e dati ausiliari integrati nel video

Technical characteristics

• SDI video inputs:
  • 1 x BNC (IN A) – 10-bit SD, HD, 2K, 3G HD levels A and B, 6G and 12G Ultra HD auto switching
  • 1 x BNC (IN B) – 10-bit SD, HD, 2K, 3G HD and 6G Ultra HD auto switching. Usable as dual link input for 4:2:2 3G or 6G UHD
• SDI video input loops:
  • 1 x BNC (IN A Loop) – reclocked, 10-bit SD, HD, 2K, 3G HD, 6G and 12G Ultra HD auto switching
  • 1 x BNC (IN B Loop) – reclocked, 10-bit SD, HD, 2K, 3 Gb/s HD, 6G Ultra HD auto switching
• SDI video outputs:
  • 1 x BNC (OUT A) – 10-bit SD, HD, 2K, 3G HD levels A and B, 6G and 12G Ultra HD auto switching
  • 1 x BNC (OUT B) – 10-bit SD, HD, 2K, 3G HD levels A and B and 6G Ultra HD auto switching. Usable as dual link output for 4:2:2 3G or 6G Ultra HD
• Quad SDI video outputs SMPTE 435-1: quad HD Split (square division method) only. Utilizes SDI out A for quadrant A, SDI out B for quadrant B; reconfigures SDI IN A loop for quadrant C, SDI IN B loop for quadrant D
• Optical fiber video inputs: 1 x 10 ­bit SD, HD, 3G HD, 2K, Ultra HD auto switching
• Optical fiber video outputs: 1 x 10­bit SD, HD, 3G HD, 2K, Ultra HD auto switching. Not available while operating in Dual Link or Quad Link output modes
• SDI audio inputs: 16 channels in SD, HD, 3G HD, 2K and Ultra HD
• SDI audio outputs: 16 channels in SD, HD, 3G HD, 2K and Ultra HD
• Optical fiber connection (optional): 1 x SMPTE optical fiber SFP socket
• Optical fiber audio inputs: 16 channels in SD, HD, 3G HD, 2K and Ultra HD
• Optical fiber audio outputs: 16 channels in SD, HD, 3G HD, 2K and Ultra HD
• Dolby support: built-in Dolby AC-3 pass-through in all conversions. Dolby E pass through except during video frame rate conversions
• Time Code inputs: support for VITC / ATC. No support for LTC
• Time Code outputs: support for VITC / ATC. No support for LTC
• Multi rate support: SDI connections are switchable between standard definition, high definition and Ultra HD. SDI switches between 270 Mb/s standard definition SDI, 1.5 Gb/s HD-SDI and 2K SDI, 3G HD, 6G and 12G Ultra HD.
• Reference input: 1 x BNC, Black Burst or Tri-level sync
• Computer interface:
  • 1 x USB 2.0 mini B port for software updates
  • 1x RJ45 10/100 Ethernet for remote control and configuration
• Processor Interface: illuminated pushbuttons, status LEDs and LCD with easy to use onscreen menus
