Blackmagic URSA Mini Pro 4.6K G2 - Professional camera with Super 35 mm 4.6K sensor up to 120 fps or 2K at 300 fps

Professional camera with Super 35 mm 4.6K sensor up to 120 fps or 2K at 300 fps

URSA Mini Pro è una cinepresa digitale che permette di ottenere un'incredibile qualità d'immagine 4.6K con le caratteristiche e i controlli propri di una telecamera broadcast tradizionale.

È dotata di un sensore Super 35 mm 4.6K con 15 stop di gamma dinamica: ottimo per i lungometraggi, può anche essere commutato istantaneamente in modalità video tradizionale per i normali lavori video. URSA Mini Pro può essere usata comodamente tutto il giorno, grazie al suo corpo compatto e perfettamente bilanciato. Inoltre, è dotata di filtri ND incorporati, attacco per obiettivo sostituibile dall'utente, oltre alla registrazione in formato RAW e ProRes su schede CFast o SD a doppio supporto.

Caratteristiche principali

• Disponibile con attacco EF, PL, F, o B4
• Sensore Super 35 HDR 4.6K sviluppato per i frame rate elevati
• Registrazione Blackmagic RAW su schede SD / UHS II / CFast o drive USB-C esterni
• Controlli esterni, touchscreen 4" all’interno dello sportellino, porta di espansione USB C, audio professionale

Ambiti di utilizzo

• Cinema
• Televisione
• Produzioni commerciali e indipendenti

Technical characteristics

Camera features

• Effective sensor size: 25.34 x 14.25 mm (Super35)
• Lens mount: EF mount included, interchangeable with optional PL, B4 and F lens mounts
• Lens control: electronic control via EF mount pins or 12 pin broadcast connector for compatible lenses
• Dynamic range: 15 stops
• Shooting resolutions: 4608 x 2592, 4608 x 1920p 2.40:1, 4096 x 2304p 16:9, 4096 x 2160p DCI, 3840 x 2160p UHD, 3072 x 2560p anamorphic, 2048 x 1152p 16:9, 2048 x 1080p DCI, 1920 x 1080p
• Frame rates: 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 fps
• High speed frame rates: Blackmagic RAW 8:1 4.6K full up to 120 fps, UHD windowed up to 150 fps, HD windowed up to 300 fps; ProRes 422 HQ 4.6K full up to 80 fps, UHD windowed up to 120 fps, HD windowed up to 240 fps
• Built in ND filters: four position ND filter wheel with clear, 2-stop, 4-stop and 6-stop ND filters
• Focus: autofocus via button or LCD touch region with compatible lenses
• Iris control: manual via wheel and touchscreen slider, auto iris via button on compatible lenses
• Screen dimensions: 4"
• Screen type: LCD capacitive touchscreen
• Metadata support: automatic lens data and recording of camera settings and slate data
• Controls: touchscreen menus, push buttons, 2 assignable shortcut keys
• Time Code clock: less than 1 frame drift every 8 hours

Connections

• Total video inputs: 1 x SDI
• Total video outputs: 1 x SDI, 1 x SDI monitoring
• SDI rates: 1.5G, 3G, 6G, 12G
• Analog audio inputs: 2 x XLR switchable between MIC, line and AES audio with Phantom power
• Analog audio outputs: 1 x 3.5 mm headphone jack, supports iPhone microphone for talkback
• Reference inputs: Tri-sync, black burst, Time Code
• Remote control: 2 x 2.5 mm LANC input for REC start/stop, iris and focus control
• Computer interface: USB Type-C 3.1 Gen 1 for external drive recording and software updates

Audio

• Microphone: integrated stereo microphone
• Built in speaker: 1 x mono speaker

Video standards

• HDMI 1080p: 23.98, 24, 25, 29.97, 30, 50, 59.94, 60
• HDMI 1080i: 50, 59.94, 60
• HDMI 2160p UHD: 23.98, 24, 25, 29.97, 30, 50, 59.94, 60
• SDI compliance: SMPTE 292M, SMPTE 424 level A and B, SMPTE 2081-1, SMPTE 2082-1
• SDI audio sampling: 48 kHz and 24 bit

Media

• Media slots: 2 x CFast 2.0, 2 x SD UHS-II, 1 x USB-C 3.1 Gen 1 expansion port
• Media format: ExFAT (Windows / Mac), HFS+ (Mac)

Supported codecs

• Blackmagic RAW Constant Bitrate 3:1, Blackmagic RAW Constant Bitrate 5:1, Blackmagic RAW Constant Bitrate 8:1, Blackmagic RAW Constant Bitrate 12:1, Blackmagic RAW Constant Quality Q0, Blackmagic RAW Constant Quality Q5, Apple ProRes XQ QuickTime, Apple ProRes 444 QuickTime, Apple ProRes 422 HQ QuickTime, Apple ProRes 422 QuickTime, Apple ProRes 422 LT QuickTime, Apple ProRes 422 Proxy QuickTime

Control

• External control: Blackmagic SDI Control Protocol, iPad control, Bluetooth control, 2 x 2.5 mm LANC

Color corrector

• Color corrector: DaVinci YRGB

Talkback and tally

• Talkback: SDI channels 15/16 and iPhone headset
• Live tally indicator: LCD, URSA Viewfinder and URSA Studio Viewfinder

Storage features

• Storage type: 2 x CFast 2.0, 2 x SD UHS-II, 1 x USB-C expansion port
• Storage rates: please see the user manual
• Recording formats: Blackmagic RAW Q0, Q5, 3:1, 5:1, 8:1, 12:1 at: 4608 x 2592p, 4608 x 1920p, 4096 x 2304p, 4096 x 2160p, 3840 x 2160p, 3072 x 2560p, 2048 x 1152p, 2048 x 1080p, 1920 x 1080p, ProRes at: 4608 x 2592p, 4608 x 1920p, 4096 x 2304p, 4096 x 2160p, 3840 x 2160p, 3072 x 2560p, 2048 x 1152p, 2048 x 1080p, 1920 x 1080p

Software

Software included: Blackmagic OS, DaVinci Resolve Studio for Mac and Windows including activation key, Blackmagic Camera Setup, Blackmagic RAW Player, Blackmagic RAW QuickLook Plugin, Blackmagic RAW SDK

Operating systems

• Mac: 13.0 Ventura, 14.0 Sonoma or later
• Windows: 10 and 11

Accessories

• Optional accessories: URSA Mini Pro PL, EF, B4 and F mounts, URSA Mini Pro Shim Kit, URSA Mini Shoulder Kit including top handle and extender arm, URSA Viewfinder, URSA Studio Viewfinder, URSA Mini SSD Recorder, URSA VLock Battery Plate, URSA Gold Battery Plate, URSA Mini Mic Mount, URSA Mini Top Handle, URSA Handgrip, Blackmagic Camera Fiber Converter

Power requirements

• Power supply: 1 x external 12 V power supply
• External power input: 1 x 4 pin XLR, 1 x 12 pin Molex connector on rear battery plate. Custom V-mount battery plate with D-tap +12V regulated output from camera.
• Power: rear camera mount compatible with industry standard V-mount or gold mount battery plates.

Physical specifications

• Dimensions: 20.2 x 16.5 x 20.9 cm
• Weight: 2.3 kg

What’s included

• Blackmagic URSA Mini Pro 4.6K G2 body
• Turret dust cap
• EF lens mount
• Power supply
• Welcome wallet with QR code for software download
• DaVinci Resolve Studio with activation key
