P4.81 rental LED display with molded connectors for curved LED walls (±10°), 500 x 1000 mm, SMD2121 LEDs, MBI5124 IC, for indoor use (1500 nits).
User benefits
Areas of use
Technical characteristics
| IC | MBI5124 |
| Curved angle | ±10° |
| Pixel pitch | 4.81 mm |
| LED type | SMD2121 |
| Panel resolution | 104 x 208 pixel |
| Physical density | 43,264 pixel/m2 |
| Brightness | ≥ 1500 cd/m2 |
| Scan method | 1/13 |
| Max. power consumption | 900 W/m2 |
| Ave. power consumption | 300 W/m2 |
| Refresh rate | ≤ 1920 Hz |
| Control mode | synchronous display with control PC by DVI |
| Protection level | IP43, indoor |
| Dimension | 500 x 1000 mm |
| Weight | 13.5 kg/panel |
