Blackmagic Camera ProDock - Device to transform the iPhone 17 Pro into a professional filmmaking tool, adding advanced connections like Time Code, Genlock and SSD recording

Device to transform the iPhone 17 Pro into a professional filmmaking tool, adding advanced connections like Time Code, Genlock and SSD recording

The Blackmagic Camera ProDock is an innovative device designed to transform the iPhone 17 Pro and 17 Pro Max into a true professional production video camera.

Compatible with the Blackmagic Camera App, this dock lets you add advanced connections to your phone, including external Time Code, Genlock, professional quality audio, SSD recording, and more, making your iPhone a powerful and versatile tool for mid- to high-end production environments.

With HDMI, USB-C, BNC, and 3.5 mm jack connections, you can integrate your iPhone with industry-standard equipment like Time Code generators, lens control accessories, and on-set monitors. The ProDock also supports advanced features like ProRes RAW and Genlock, which are essential for multi-camera and virtual productions. This prevents issues like flickering on LED walls and makes editing with DaVinci Resolve easier.

The design includes three USB-C ports for accessories and high-speed SSDs, a power management system that allows all connected devices to be powered simultaneously, and a standard HDMI output for real-time monitoring on an external monitor. The user interface, inspired by Blackmagic digital video cameras, allows you to adjust settings like frame rate, ISO, and white balance with a single touch, and you can record directly to the Blackmagic Cloud in standard formats up to 4K.

ProDock is an elegant and powerful solution for those who want to take full advantage of the iPhone's video capabilities in professional settings.

Technical characteristics

Connections

• HDMI video outputs: 1 x HDMI 2.1 (type a)
• Outputs resolution and frame rate set in blackmagic camera for iOS
• Audio inputs: 1 x 3.5 mm stereo mini-jack
• Audio outputs: 1 x 3.5 mm stereo mini-jack
• Time Code input: 1 x BNC, 1 x 3.5 mm audio input supports Time Code IN
• Genlock input: 1 x BNC, tri-sync or black burst
• Genlock supported on iPhone 17 pro and iPhone 17 pro max
• USB-C ports: 2 x USB 3.2 high speed ports for recording to external media
• 1 x USB 2.0 port for accessories
• Power: 12 to 15 V_DC input with locking 5.5 mm barrel connector
• iPhone connection: 1 x USB-C cable and plug

Audio

• Microphone: connect external microphones via the 3.5 mm stereo mini-jack, or USB‑C ports
• Monitor: connect headphones via the 3.5 mm stereo mini-jack audio output

Media

• Record Blackmagic camera clips to internal iPhone storage or external storage connected by USB

Display

• Status indicator: 1 x power LED indicator
• 1 x front tally LED indicator
• 1 x genlock LED indicator

Software

• Blackmagic camera for iOS: download for free on the app store

Operating system

• Supported on iPhones running iOS 26 or later
• Some features dependent on iPhone model

Power

• Power supply: 1 x external 12 V_DC 60 W power supply
• Power inputs:
• 12 to 15 V_DC input with locking 5.5 mm barrel connector
• Power outputs: 5 V_DC 1.5 A 7.5 W max. output each USB‑C port

Environmental specifications

• Operating temperature: 0 to 40 °C
• Storage temperature: 20 to 45 °C
• Relative humidity: 0% to 90% non-condensing

Physical specifications

• Dimensions: 16.3 x 2.54 x 6.6 cm
• Weight: 270 g

What's in the box

• Blackmagic camera prodock
• 1/4" to 1/4" mounting adapter
• External 12 V_DC power supply with locking connector and international socket adapters
• Welcome wallet with QR code for software download
