In the latest video published on the Audio Effetti Stream channel, our Pre Sales Manager Roberto Villa introduces EasyFLEX by EGO Display, an indoor LED solution designed to address one of the most common challenges in professional installations: adapting to real architectural spaces.
In many indoor LED projects, the true limitation is not the pixel pitch but the available space. Columns, corners, irregular heights or mandatory rear access often require custom solutions, leading to higher costs and longer lead times. EasyFLEX was developed specifically to overcome these constraints.
Available in P2.5 and P1.9 pixel pitches and in multiple cabinet formats — 250×750 mm, 250×500 mm, 500×500 mm and 500×1000 mm — with optional 45-degree cut corners, EasyFLEX enables the creation of custom LED walls using standard components. This configuration allows displays to be tailored to real spaces without compromising the design.
At the core of EasyFLEX is a fully rotatable cabinet and module system. The mechanical structure is identical on both the top and side of the cabinet, allowing panels to be rotated and combined freely to achieve the desired geometry, both horizontally and vertically, without affecting colour consistency.
EasyFLEX-P2.5-100 - Indoor, 3-in-1 SMD, 800 nit, 5000:1, ≥ 3840 Hz, 500 x 1000 mm, 10 kg high-performance LED panel, flexible design, right angle splicing for option
CHF 804,73
EasyFLEX-P2.5-25x50 - Indoor, 3-in-1 SMD, 800 nit, 5000:1, ≥ 3840 Hz, 250 x 500 mm, 3.5 kg high-performance LED panel, flexible design, right angle splicing for option
CHF 318,31
EasyFLEX-P2.5-25x75 - Indoor, 3-in-1 SMD, 800 nit, 5000:1, ≥ 3840 Hz, 250 x 750 mm, 4.5 kg high-performance LED panel, flexible design, right angle splicing for option
CHF 440,01
Each module features a dual rear connection rotated by 90 degrees, ensuring correct orientation regardless of cabinet rotation. This makes it possible to build LED walls in 25 cm increments in both width and height, using the available cabinet formats without resorting to custom designs, reducing additional costs and shortening delivery times.
From a performance standpoint, EasyFLEX uses 3-in-1 SMD technology, delivers 800 nits of brightness, a 5000:1 contrast ratio, and a refresh rate of ≥3840 Hz. These specifications ensure stable and smooth images, making the display suitable for video recording and broadcast applications. A high-brightness version of up to 3500 nits is also available for semi-outdoor environments or spaces with high ambient light.
The structure integrates a rigid module connection system, improving signal stability and enabling fast assembly and disassembly. The compact design features a combined receiving card and HUB board, while the plug-in power system further simplifies installation and maintenance.
EasyFLEX supports front service maintenance, reducing intervention time, and is designed with a dust-protected structure to ensure reliability and long-term durability even in demanding environments. The rear of the cabinet is completely free of exposed cables, an important advantage for visible installations or applications with pedestrian access behind the display. Tamper-proof protective covers are also available.
EasyFLEX is particularly well suited for shopping centres, retail stores with rear pedestrian access, airports, metro stations, trade shows and broadcast environments — all contexts where installation flexibility and operational continuity are essential.
In summary, EasyFLEX by EGO Display is not simply an indoor LED panel, but a true design platform that reduces installation complexity, optimises time and cost, and provides maximum creative freedom while maintaining solid and reliable performance over time.
EasyFLEX-P1.9-25X50 - Indoor, 3-in-1 SMD, 800 nit, 5000:1, ≥ 3840 Hz, 250 x 500 mm, 3.5 kg high-performance LED panel, flexible design, right angle splicing for option
CHF 380,00
EasyFLEX-P1.9-25X75 - Indoor, 3-in-1 SMD, 800 nit, 5000:1, ≥ 3840 Hz, 250 x 750 mm, 4.5 kg high-performance LED panel, flexible design, right angle splicing for option
CHF 507,92
EasyFLEX-P1.9-100 - Indoor, 3-in-1 SMD, 800 nit, 5000:1, ≥ 3840 Hz, 500 x 1000 mm, 10 kg high-performance LED panel, flexible design, right angle splicing for option
CHF 1.034,65
Watch the video or subscribe to our YouTube channel!
If you would like to learn more about EGO Display EasyFLEX, watch the video or visit our YouTube channel and subscribe today: www.youtube.com/c/AudioEffettiStream
